| 触点形式 Contact form | 常开型 Normally open | 常闭型 Normally closed | 高电压常开型 Normally open high voltage | 高电压常闭型 Normally closed high voltage |
| 最大触点容量 contact rating max. | 10W | 50W |
| 最大开关电压 Switching voltage max. | DC200V AC140V | DC220V AC250V |
| 最小击穿电压 Breakdown voltage min. | 250V | 580V |
| 最大负载电流 Carry current max. | DC1.0A | DC3.0A |
| 最大开关电流 Switching current max. | 0.5A | 1.0A |
| 最大接触抗阻 Contact resistance initial max | 0.2Ω | 0.2Ω |
| 最小绝缘抗阻 Insulation resistance min. | 106 mΩ | 106 mΩ |
| 工作温度 Operating temperature | -40~+150℃ | -40~+150℃ |
